DS1832 - 3.3V MicroMonitor芯片

DS1832是Maxim美信半导体公司的一款监控电路、电压监测、排序产品，DS1832是3.3V MicroMonitor芯片，本站介绍了DS1832的封装应用图解、特点和优点、功能等，并给出了与DS1832相关的Maxim元器件型号供参考。

DS1832 - 3.3V MicroMonitor芯片 - 监控电路、电压监测、排序 - Maxim美信半导体高性能芯片品质 - 美信半导体

产品概述

The DS1832 3.3-volt MicroMonitor Chip is pin-compatible with the industry-standard DS1232 and operates in both 3.0- and 3.3-volt environments. Like the DS1232, the DS1832 monitors power supply, software execution, and an external pushbutton override. It is designed with CMOS outputs and is capable of maintaining a valid output on the active low reset to 0 volts with a 100kΩ pull-down resistor. On power-up, the DS1832 holds reset for 250ms to allow the system to stabilize.

Moving a design from 5 volts to 3.3 volts can be as simple as substituting the DS1832 for the DS1232 and removing the pull-up resistor on the active low reset. This makes it a versatile, space- and cost-saving monitor for any processor-driven system requiring reliable operation.

关键特性

热门应用
