MAX4016 - 典型电路框图：
MAX4016典型电路框图
Maxim美信半导体芯片：
承诺原装正品
专营Maxim美信，真正优化您的供应链
Maxim产品 - MAX4016介绍

MAX4016 - 低成本、高速、单电源运算放大器，满摆幅输出

MAX4016是Maxim美信半导体公司的一款视频芯片产品，MAX4016是低成本、高速、单电源运算放大器，满摆幅输出，本站介绍了MAX4016的封装应用图解、特点和优点、功能等，并给出了与MAX4016相关的Maxim元器件型号供参考。

MAX4016 - 低成本、高速、单电源运算放大器，满摆幅输出 - 视频芯片 - Maxim美信半导体高性能芯片品质 - 美信半导体

产品概述

The MAX4012 single, MAX4016 dual, MAX4018 triple, and MAX4020 quad op amps are unity-gain-stable devices that combine high-speed performance with Rail-to-Rail outputs. The MAX4018 has a disable feature that reduces power-supply current to 400µA and places its outputs into a high-impedance state. These devices operate from a 3.3V to 10V single supply or from ±1.65V to ±5V dual supplies. The common-mode input voltage range extends beyond the negative power-supply rail (ground in single-supply applications).

These devices require only 5.5mA of quiescent supply current while achieving a 200MHz -3dB bandwidth and a 600V/µs slew rate. These parts are an excellent solution in low-power/low-voltage systems that require wide bandwidth, such as video, communications, and instrumentation. In addition, when disabled, their high-output impedance makes them ideal for multiplexing applications.

The MAX4012 comes in a miniature 5-pin SOT23 package, while the MAX4016 comes in 8-pin µMAX® and SO packages. The MAX4018/MAX4020 are available in a space-saving 16-pin QSOP, as well as a 14-pin SO.

关键特性
  • 以下关键特性由Maxim美信半导体提供：
  • Low-Cost
  • High Speed:
  • 200MHz -3dB Bandwidth (MAX4012)
  • 150MHz -3dB Bandwidth (MAX4016/4018/4020)
  • 30MHz 0.1dB Gain Flatness
  • 600V/µs Slew Rate
  • Single 3.3V/5.0V Operation
  • Rail-to-Rail Outputs
  • Input Common-Mode Range Extends Beyond VEE
  • Low Differential Gain/Phase: 0.02%/0.02°
  • Low Distortion at 5MHz:
  • -78dBc SFDR
  • -75dB Total Harmonic Distortion
  • High-Output Drive: ±120mA
  • 400µA Shutdown Capability (MAX4018)
  • High-Output Impedance in Off State (MAX4018)
  • Space-Saving SOT23, SO, µMAX, or QSOP Packages
    • 热门应用
  • 模数转换器接口
  • 电池供电仪表
  • CCD成像系统
  • 机顶盒
  • 视频监视系统
  • 视频线驱动器
  • 视频路由与切换系统
